Product Specs: Networks
14 Port MIL Switch
10/100 Mbps switch.
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Connections:
Front:
14 X LAN 10/100 or 10/100/1000 Mbps (Mighty Mouse)
1 X DC in, 10-32V DC Mil connector
Back:
2 x LAN 10/100/1000 Mbps (Mighty Mouse)
1 x Service Port
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Connections:
Front:
14 X LAN 10/100 or 10/100/1000 Mbps (Mighty Mouse)
1 X DC in, 10-32V DC Mil connector
Back:
2 x LAN 10/100/1000 Mbps (Mighty Mouse)
1 x Service Port
10/100 Mbps switch.
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Connections:
1 X DC in, 10-32V DC Mil connector
14 X RJ45
(Rugged Amphenol)
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Connections:
1 X DC in, 10-32V DC Mil connector
14 X RJ45
(Rugged Amphenol)
14 Port Switch
8 port POE Switch
RS232 LAN Switch
8-port LAN switch with Power Over Ethernet on all 8 channels.
Power Over Ethernet standard IEEE802.3af (48V, max output 12,8W per channel)
Max power consumption 125W
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -20 - +40 Celsius
Storage: -40 - +70 Celsius
Connections:
8 X RJ45 (10/100 Mbit)
Rugged Amphenol
1 X DC in, 10-32V DC Mil connector
Power Over Ethernet standard IEEE802.3af (48V, max output 12,8W per channel)
Max power consumption 125W
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -20 - +40 Celsius
Storage: -40 - +70 Celsius
Connections:
8 X RJ45 (10/100 Mbit)
Rugged Amphenol
1 X DC in, 10-32V DC Mil connector
Switch for sharing serial devices in a network. (LAN, WAN, etc)
Individual IP addressing to each serial port.
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
1 X LAN RJ45 (10/100 Mbps)
1 X LAN Fiber SC Multimode (100MBit, 1300nm)
10-32V DC in
6 X DSUB 9-p
Individual IP addressing to each serial port.
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
1 X LAN RJ45 (10/100 Mbps)
1 X LAN Fiber SC Multimode (100MBit, 1300nm)
10-32V DC in
6 X DSUB 9-p
Serial switch for sharing serial devices in a network (LAN, WAN etc).
Individual IP addressing to each serial port.
Software switchable between RS232, RS422 and RS485.
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
6 X RS (DSUB, 9 pin)
1 X LAN RJ45 (10/100 Mbit)
1 X DC in, 10-32V DC Mil connector
Individual IP addressing to each serial port.
Software switchable between RS232, RS422 and RS485.
Designed to meet: MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
6 X RS (DSUB, 9 pin)
1 X LAN RJ45 (10/100 Mbit)
1 X DC in, 10-32V DC Mil connector
10/100 Mbps switch.
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
6 X LAN Fiber SC Multimode (100MBit, 1300nm)
2 X LAN RJ45 (10/100 Mbps)
1x DC in, 10-32V
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports:
6 X LAN Fiber SC Multimode (100MBit, 1300nm)
2 X LAN RJ45 (10/100 Mbps)
1x DC in, 10-32V
6 Port Fiber Switch
RS232/422/485 Switch
